Helkama X 10sp 29”
Helkama X is a hardtail e-mountain bike for forest rides and commuting. It features a powerful Shimano motor and an elegant daytime running light integrated in the frame.
3999,00 €
Find closest dealerHelkama X
The Helkama X electric mountain bike is a one-bike solution for all your needs – it’s your choice when you want excellent riding comfort, whether you’re heading for a fast-paced commute or a relaxed off-road ride. The electric mountain bike has a modern geometry and a lower and shorter frame, which allows for more agile cornering on winding forest trails.
The X electric mountain bike’s stunning range of colours makes it a striking bike with a tough paint finish that withstands splashes and bumps on fast-paced off-road adventures. A DRL daytime running light is integrated into the bike frame, which improves your visibility in traffic and always lights up when the motor is on.
The electric mountain bike is equipped with high-quality Schwalbe 29"" off-road tyres for varying surfaces and a RockShox 130mm front suspension fork. Ergon handlebar grips and a gel saddle provide extra comfort when riding off-road.
Advanced technology
With Shimano’s powerful 85Nm motor, you can pedal more paths and climb steep uphills effortlessly. Thanks to the long-lasting 630 Wh battery, you can fully enjoy the freedom of your mountain bike and new routes.
The X electric mountain bike is equipped with the Shimano Linkglide drive system, which ensures seamless gear changes and smooth riding. Linkglide technology reduces wear and tear in the drive system and reduces jolting and jumping when changing gears.
• Motor: Shimano EP6, 85 Nm
• Battery: Shimano BT-EN806, 630 Wh
• Display: Shimano SC-EN600
• Charger Shimano EC-E6002
Motor
Shimano EP6 85Nm 250W 25km/h
The EP6 drive unit offers EP8-level e-bike performance at a lower price and still offers 85 Nm of torque.
Battery
Shimano BT-EN806
A high-capacity frame-integrated battery, ideal for those who want to ride longer between charges. Compact design and low centre of gravity for a more natural riding experience.
Display
Shimano SC-EN600
The compact unit is easy to place safely on the handlebar. The colour display can also be read in bright sunlight.
Additional information
| Product name | Helkama X 10v 29” |
|---|---|
| Brand | Helkama |
| Frame | Aluminum |
| Frame size | M (17"), L (19"), XL (21") |
| Front fork | RockShox 35 Gold RL 29" 130 51mm MXL Stealth |
| Transmission | Shimano Deore RD-M5130 10sp Linkglide |
| Gear amount | 10 |
| Shifter | Shimano Deore SL-M5130 10sp Linkglide |
| Front brakes | Shimano MT410 CL hydraulic disc brake 203mm |
| Rear brakes | Shimano MT410 CL hydraulinen levyjarru 180mm |
| Brake lever | Shimano MT-401 |
| Crank set | FSA CK-752 165mm , 34H Shimano CRE-70B |
| Chain | Shimano CN-LG500 Linkglide |
| Rims | Mach1 Trucky 30-622 ETR / 32H, tubeless ready |
| Saddle | Ergon ST10 GEL |
| Seatpost | 30,9 x 350 mm |
| Handlebar | Alumiini 780mm(17" 720mm) |
| Stem | Satori URSA 50 mm |
| Rear axle measurements | 12mm/177mm |
| Tires | Schwalbe Nobby Nic |
| Wheel size | 29" |
| Tire size ETRTO | 62-622 |
| Motor brand | Shimano |
| Motor model | Shimano EP6 |
| Motor specifications | 250W – 36V – 85Nm- 25km/h |
| Battery model | Shimano EN806 |
| Battery Energy (Wh) | 630 |
| Battery placement | Integrated |
| Battery charging time | 80 % 7,5 h/ 100 % 10,2 h |
| Charger | Shimano E6002 |
| Display | Shimano EN600 |
| Color | graphite gray, lagoon green, violet |
| Painoraja (kg) | 145 |
| Recommended height | |
| Weight (kg) | 24 |
Helkama X 10sp 29”: m-17
| fs ‐ Frame size | 17" |
|---|---|
| st ‐ Seat tube length | 430 |
| tt ‐ Effective top tube length | 609,8 |
| ht ‐ Head tube length | 125 |
| hta ‐ Head tube angle | 67,5 |
| sta ‐ Seat tube angle | 74,5 |
| cs ‐ Chainstay length | 460 |
| bd ‐ Bottom bracket drop | 56,5 |
| fo ‐ Fork rake/offset | 546 |
| s ‐ Stack | 657,4 |
| r ‐ Reach | 427,5 |
| wb ‐ Wheelbase | 1188 |
Helkama X 10sp 29”: l-19
| fs ‐ Frame size | 19" |
|---|---|
| st ‐ Seat tube length | 470 |
| tt ‐ Effective top tube length | 630 |
| ht ‐ Head tube length | 135 |
| hta ‐ Head tube angle | 67,5 |
| sta ‐ Seat tube angle | 74,5 |
| cs ‐ Chainstay length | 460 |
| bd ‐ Bottom bracket drop | 56,5 |
| fo ‐ Fork rake/offset | 546 |
| s ‐ Stack | 666,6 |
| r ‐ Reach | 445 |
| wb ‐ Wheelbase | 1209,4 |
Helkama X 10sp 29”: xl-21
| fs ‐ Frame size | 21" |
|---|---|
| st ‐ Seat tube length | 515 |
| tt ‐ Effective top tube length | 649,4 |
| ht ‐ Head tube length | 145 |
| hta ‐ Head tube angle | 67,5 |
| sta ‐ Seat tube angle | 74,5 |
| cs ‐ Chainstay length | 460 |
| bd ‐ Bottom bracket drop | 56,5 |
| fo ‐ Fork rake/offset | 546 |
| s ‐ Stack | 675,8 |
| r ‐ Reach | 462 |
| wb ‐ Wheelbase | 1230,3 |
